| 流量Q | 功率 | |||||||
| Capacity | 揚程 | 轉速 | Power（N） | 效率 | 允許吸上真空高度 | |||
| 泵型號 | Head | Speed | Eff | A.S.L | ||||
| Pump type | （H） | （n） | 軸功率 | 電機功率 | (n) | （HS） | ||
| 米3/時 | 升/秒 | 千瓦 | 千瓦 | |||||
| m3/hr | i/s | Input power | Motor power | |||||
| （KW） | (KW) | |||||||
| 0.36 | 0.1 | 28 | 0.196 | 14 | 7 | |||
| 20W-20 | 0.72 | 0.2 | 20 | 2900 | 0.178 | 0.75 | 22 | 6.5 |
| 0.9 | 0.25 | 15 | 0.175 | 21 | 6 | |||
| 0.79 | 0.22 | 40 | 707 | 1.1 | 17 | 6.5 | ||
| 25W-25 | 1.44 | 0.4 | 25 | 2900 | 0.378 | 0.75 | 26 | 6 |
| 1.8 | 0.5 | 18 | 0.353 | 25 | 5.5 | |||
| 1.73 | 0.48 | 52 | 1.247 | 2.2 | 21 | 6.5 | ||
| 30W-30 | 2.88 | 0.8 | 30 | 2900 | 0.97 | 1.5 | 24 | 6 |
| 3.6 | 1 | 20 | 0.632 | 31 | 5.5 | |||
| 3.6 | 1 | 60 | 2.36 | 4 | 25 | 6 | ||
| 40W-40 | 5.4 | 1.5 | 40 | 2900 | 1.73 | 3 | 34 | 5 |
| 6.48 | 1.8 | 26 | 1.35 | 34 | 4 | |||
| 6.12 | 1.7 | 66 | 5.32 | 7.5 | 30 | 5 | ||
| 50W-45 | 9 | 2.5 | 45 | 2900 | 3.06 | 5.5 | 36 | 4 |
| 10.8 | 3 | 28 | 2.35 | 35 | 3 | |||
| 10.1 | 2.8 | 84 | 7.97 | 29 | 4.5 | |||
| 65W-50 | 14.4 | 4 | 50 | 2900 | 5.03 | 11 | 39 | 3.5 |
| 16.9 | 4.7 | 30 | 3.74 | 37 | 2.5 | |||
| 0.36 | 0.1 | 80 | 1.12 | 7 | 6.5 | |||
| 20W-65 | 0.72 | 0.2 | 65 | 2900 | 0.85 | 2.2 | 15 | 6 |
| 0.9 | 0.25 | 50 | 0.816 | 15 | 5.5 | |||
| 0.792 | 0.22 | 110 | 2.596 | 4 | 13 | 6 | ||
| 25W-70 | 1.44 | 0.4 | 70 | 2900 | 2.374 | 3 | 22 | 5.5 |
| 1.8 | 0.5 | 52 | 1.11 | 2.2 | 23 | 5 | ||
